Rotor X Aircraft

Continuing the RotorWay Legacy into the future of aviation

_03

The World's #1 Two Seat Helicopter Company

The Phoenix A600 Turbo is the world’s most affordable and capable two-seat helicopter. With a cruise speed of 95mph, a range of 170 miles (or 320 miles with the extended range tank,) and a 655lb payload, the new A600 Turbo is the perfect helicopter for both new and experienced pilots.

The 180hp turbo engine is more than enough power to pick up two heavy men with full fuel. Rotor X Aircraft offers transition training and free technical support, but we also have plenty of other resources such as third-party builder assist programs and access to CFI’s all over the country to help you get your helicopter rating.

Honoring our dear friends Mark Peterson and Tom Volz

We’re thankful for all the years of wonderful memories and all the knowledge and passion that Mark and Tom have brought to the community.

It is truly an honor to have been a part of their lives and it is our promise to continue their story and love for aviation.

Our hearts and prayers go out to the Peterson and Volz families.

The World's #1 Kit Helicopter

Introducing the new Phoenix A600 Turbo

Specifications

General Specs:

Horsepower: 180 HP
Gross Weight: 1,630 lbs
Empty Weight: 975 lbs
Useful Load: 655 lbs
Pilot, Passenger, Baggage: 545 lbs

Dimensions:

Length (with blades): 29.5ft
Length (without blades): 22ft
Width (skid to skid): 72in
Width (fuselage): 44in
Height (Blades on): 10.9ft
Height (Blades off): 8.5ft

Performance

Max Speed: 115 mph
Cruise Speed: 95 mph
Max Sideways, Rearward Airspeed: 20 mph
Fuel Consumption: 8 gallons per hour, 30 liters per hour
Fuel Capacity: 17 gallons (31 gallons with aux tank)
Hover in Ground Effect (HIGE): 9,000 ft
Hover Out of Ground Effect (HOGE): 7,000 ft
Service Ceiling: 11,500 ft

Kit Features

MGL EFIS with GPS
Dual ECU System
Dual Ignition System
Cabin Heating
Removable Doors
Customizable Dashboard Panel

Options and Upgrades

A600 Governor
Extended Range Fuel Tank
Cargo Pod
LED Light Package
Lowered Seat Package
Air Conditioning
10.4 inch MGL Glass Display
Avionics Package (radio, transponder, ADS-B)

Additional Resources

Build Assist and Flight Ready Options
Free Technical Support for Builders
Transition Training
Annual Fly-ins around the United States

Rotor X Projects

Helicopter kits

Phoenix A600 Turbo

Place your order today on the world's most capable and affordable two-seat helicopter.

Ultralight evtol

Dragon Personal Air Vehicle

Fly without a full helicopter license with the best new ultralight eVTOL, DRAGON.

Help and Support

Parts and Maintenance

Rotor X Aircraft provides support for older RotorWay models such as the Exec 162F. Order parts by emailing parts@rotorxaircraft.com.

Future Projects

Pricing

Due to a backlog of orders, the Phoenix A600 Turbo is not currently available for sale.

The Process

Reserve your spot in line by placing an order today. Contact us with any questions, your name, email address, phone number, and shipping address and we'll send a purchase agreement for you to review.

Timeframe

Due to an increase in demand, we have improved our factory by replacing many vendors and fabricating more parts in-house. This means that new orders can get started on their builds in as little as 4 months.

Builder Assist

Don't have the space or time to assemble your kit at home? Rotor X Aircraft has relationships with builder assist programs with qualified builders. Email us for more information at sales@rotorxaircraft.com

Phoenix A600 Turbo

$ 138,000

with a 50% deposit

180hp Turbo Engine
Range: 170 miles (320 with aux tank)
Cruise Speed: 95mph
Useful Load: 655lb
Service Ceiling: 11,500ft

Not Currently For sale

Popular

Phoenix A600 Turbo

$ 130,000

paid at signing

180hp Turbo Engine
Range: 170 miles (320 with aux tank)
Cruise Speed: 95mph
Useful Load: 655lb
Service Ceiling: 11,500ft

Not currently for sale

$8k Discount

Get in touch with us

Send us a message below if you have questions, need parts, or if you are ready to place an order. We will be in touch soon.

Rotor X Events

june 20-25

Montana Fly-in

Second annual Northwest Gathering is less than 2 months away! June 20-25 in Harlowton Montana. Please contact me if you plan to attend. Camping available on sight and at local rv park. Go to https://www.misneraviation.com/new-events got more information or contact me at 406-272-7902 or daniel@misneraviation.com
